Place of Origin | CHINA |
Brand Name | Cummins Diesel Generators |
Certification | ISO9001 |
Model Number | FM100KW |
Document | Product Brochure PDF |
Low Sound Cummins Diesel Truck Engines with Excellent Fuel Economy
Cummins Diesel Generators offer reliable and efficient diesel power for marine, commercial and industrial applications. Built with the highest quality Cummins marine diesel engines, these generators offer superior power output with frequencies of 50/60 Hz, power output from 5 to 3000 KW and speed of 1500/1800 Rpm. Their digital controllers ensure accurate and reliable performance and the low noise level makes these generators suitable for any environment. Whether you need to power a vessel at sea, a commercial building or an industrial site, Cummins Diesel Generators are the ideal choice for reliable and efficient diesel power.
Parameters | Technical Specifications |
---|---|
Fuel Consumption | Low |
Noise Level | Low |
Alternator | Brushless |
Controller | Digital |
Fuel Type | Diesel |
Warranty | 1-2 Years |
Durability | High |
Cooling System | Air/Water Cooled |
Power Output | 5-3000 KW |
Speed | 1500/1800 Rpm |
Cummins Diesel Generators are designed for a wide range of applications. The model FM100KW is a reliable electric diesel generator that is both EPA certified and ISO9001 certified, meaning that it meets the highest standards of quality and safety. It is powered by a brushless alternator and runs at either 1500 or 1800 RPM. The fuel type is diesel and it comes with a 1-2 year warranty. Supplied by a trusted Chinese manufacturer, the Cummins Diesel Generator is the perfect choice for those looking for a reliable source of energy. The minimum order quantity is 1 and the price is US$ 7500-8500 per set with plywood packing. The delivery time is usually within 3-5 weeks.
Cummins Diesel Generators are ideal for many applications, from powering small businesses to large industrial facilities. The generators are highly durable and able to provide reliable power even in the harshest of conditions. The generator parts are readily available and can be easily replaced in the event of a breakdown. The generator sets are also designed to be easily maintained, ensuring that they will be able to provide reliable power for many years. With its EPA certification and ISO9001 certification, the Cummins Diesel Generator is the perfect choice for those looking for a reliable source of energy.
Customized services for Cummins Diesel Generators are available. Cummins Marine Diesel Engines, CUMMINS Diesel Generator Set, Cummins Diesel Generator Parts, are all from the trusted brand name of Cummins Diesel Generators. This FM100KW generator is certified with ISO9001, EPA Certified emission standard and provides a high level of durability. The minimum order quantity is 1 set, and the price range is from US$ 7500-8500/Set (FOB Price). Packaging details include plywood packing, and delivery time is 3-5 weeks. Payment terms are T/T, with a supply ability of 1000. It has a digital controller and a low fuel consumption, making it an efficient and reliable generator with an air/water cooled cooling system.
Cummins Diesel Generators provide technical support and services for customers. Our services include:
Cummins Diesel Generators: Packaging and Shipping
Cummins Diesel Generators are shipped by air, sea, or land, depending on the size and weight of the product. All generators are securely packaged to ensure that they arrive in perfect condition.
Smaller generators are generally packaged in a corrugated cardboard box that is reinforced with extra padding to protect against shock and vibration. Larger generators are often packaged in a heavy-duty wooden crate with foam padding and straps to secure the generator in place.
All packages are labeled with the contents, destination, and handling instructions. In addition, each package is also clearly marked with the Cummins logo.
Model | Diesel Generator | Diesel Engine | Alternator | Size (mm) |
Weight(KG) | |||
Prime Power (KW/KVA) |
Max Power (KW/KVA) |
Model |
Power (KW) |
Model |
Power (KW/KVA) |
|||
16GF | 16/20 | 18/22 | 4B3.9-G1 | 24 | PI144D | 16/20 | 1800×760×1430 | 780 |
20GF | 20/25 | 22/28 | 4B3.9-G1 | 24 | PI144E | 20/25 | 1800×760×1430 | 800 |
22GF | 22/28 | 24/30 | 4B3.9-G1 | 24 | PI144F | 22/28 | 1800×760×1430 | 830 |
24GF | 24/30 | 26/33 | 4BT3.9-G1 | 36 | PI144G | 24/30 | 1800×760×1430 | 846 |
28GF | 28/35 | 31/39 | 4BT3.9-G1 | 36 | PI144H | 28/35 | 1800×760×1430 | 880 |
32GF | 32/40 | 35/44 | 4BT3.9-G1 | 36 | PI144J | 32/40 | 1800×760×1430 | 896 |
34GF | 34/43 | 37/47 | 4BT3.9-G1 | 36 | PI144K | 34/43 | 1800×760×1430 | 906 |
40GF | 40/50 | 44/55 | 4BTA3.9-G2 | 50 | U I224D | 40/50 | 1900×760×1430 | 1030 |
48GF | 48/60 | 53/66 | 4BTA3.9-G2 | 50 | U I224E | 48/60 | 1900×760×1430 | 1050 |
58GF | 58/73 | 64/80 | 6BT5.9-G1 | 92 | U I224F | 58/73 | 2150×830×1496 | 1215 |
68GF | 68/85 | 74/94 | 6BT5.9-G1 | 92 | U I224G | 68/85 | 2150×830×1496 | 1255 |
80GF | 80/100 | 88/110 | 6BT5.9-G1 | 92 | U I274 | 80/100 | 2150×830×1496 | 1300 |
96GF | 96/120 | 106/132 | 6BTA5.9-G2 | 110 | U I274D | 96/120 | 2150×830×1496 | 1335 |
112GF | 112/140 | 123/154 | 6BTAA5.9-G2 | 120 | U I274E | 112/140 | 2150×830×1496 | 1425 |
128GF | 128/160 | 141/176 | 6 TA8.3-G2 | 163 | U I274F | 128/160 | 2450×850×1516 | 1695 |
144GF | 144/180 | 158/198 | 6 TA8.3-G2 | 163 | U I274G | 144/180 | 2450×850×1516 | 1815 |
160GF | 160/200 | 176/220 | 6 TAA8.3-G2 | 183 | U I274H | 160/200 | 2540×945×1550 | 1874 |
184GF | 184/230 | 202/253 | 6LTAA8.9-G2 | 220 | U I274J | 184/230 | 2540×945×1550 | 2020 |
200GF | 200/250 | 220/275 | 6LTAA8.9-G2 | 220 | J I274K | 200/250 | 2540×945×1550 | 2080 |
240GF | 240/300 | 264/330 | NTA855-G1A | 261 | H I444D | 240/300 | 3150×1120×1630 | 2970 |
260GF | 260/325 | 286/358 | NTA855-G1B | 283 | H E444ES | 260/325 | 3100×1100×1635 | 3198 |
280GF | 280/350 | 308/385 | NTA855-G2A | 313 | H I444E | 280/350 | 3100×1100×1635 | 3198 |
304GF | 304/380 | 334/418 | NTAA855-G7 | 343 | H I444FS | 304/380 | 3250×1190×1700 | 3200 |
320GF | 320/400 | 352/440 | NTAA855-G7A | 370 | H I444F | 320/400 | 3300×1150×1700 | 3260 |
400GF | 400/500 | 440/550 | KTA19-G4 | 457 | H I544 | 400/500 | 3500×1375×1980 | 3950 |
450GF | 450/563 | 495/619 | KTAA19-G5 | 470 | H I544D | 450/563 | 3700×1750×2030 | 4200 |
500GF | 500/625 | 550/688 | KTAA19-G6A | 554 | H I544FS | 500/625 | 3700×1750×2030 | 4200 |
600GF | 600/750 | 660/825 | KTA38-G2 | 664 | LVI634B | 600/750 | 4490×1630×2430 | 7800 |
640GF | 640/800 | 704/880 | KTA38-G2 | 664 | H I634G | 640/800 | 4490×1630×2430 | 8500 |
720GF | 720/900 | 792/990 | KTA38-G2A | 813 | H I634H | 752/940 | 4490×1630×2430 | 8560 |
800GF | 800/1000 | 880/1100 | KTA38-G5 | 880 | H I634J | 824/1030 | 4510×1850×2500 | 9120 |
900GF | 900/1125 | 990/1238 | KTA38-G9 | 990 | H I634K | 900/1125 | 4850×1850×2500 | 9400 |
1000GF | 1000/1250 | 1100/1375 | KTA50-G3 | 1115 | PI734A | 1008/1260 | 4950×2080×2560 | 10120 |
1200GF | 1200/1500 | 1320/1650 | KTA50-G8 | 1299 | PI734 | 1240/1550 | 5400×2195×2560 | 10600 |
