Sturdy Housing 100kw Cummins 50hz Generator 400/230v Low Maintenance

100kw silent diesel generators 125 kva power gen set for sale 100 kw with Cummins generator price

100kw diesel generator 125kva genset price for africa

100KW DIESEL GENERATOR DETAILS
Model	100GF	Start Method	DC 24
Generator Prime Power(KW)	100	Output Current(A)	180
Standby Power(KW)	110	Voltage(V)	400/230
Power Factor	0.8	Phase	Three phase, Four Wires
Frequency(Hz)	50/60	Weight(kg)	1700
Size(mm)	L	W	G
	2400	720	1500
Diesel Engine Data
Manufacturer	Ricardo Engine	Model	R6105AZLD
Rated Speed(Rpm)	1500/1800	Diesel Engine Max Power(KW/H)	121
Cylinder No.	6	Arrangement Type	In-line
Bore*Stroke(mm)	105*125	Displacement(L)	6.75
Intake Method	Turbocharged	Compression ratio	16.0:1
Fuel	Diesel Fuel	Full Load Consumption(g/kw.h)	≤218
Oil Capacity(L)	18	Start Method	Electrical
Engine Cooled Method	Radiator Max 40ºC,fans are driven by belt with safety guard.
Alternator Data
Manufacturer	Stanford	Model	XN224DS
Rated Power(KVA/KW)	125/100	Excitation Type	Brushless
Insulation Class	H	Protection Grade	IP22
Unload Voltage Adjustment	≥±5%	Stable Voltage Adjustment	±1%
Efficiency (%)	94.8	Voltage Control Method	AVR

1. Complete 100kw diesel generator adopt Weichai engine R4105ZD model.This type can be used as prime work or backup use.Adopt UK Ricardo technology produced in China.Easy operation,simple maintenance and spare parts available all times.
2. Complete generator can be used for farm ,construction area,fix area etc as prime work use ,also can used for school,home,factory, hospital,government work area as back up use etc.
3. Alternator adopt 100% copper wires type brush-less model.100% power output,easy maintenance and reliable quality.
4. Complete generator with smart controller with protection system.make Full control of speed,temperate,loading power etc.Make sure generator keep good running conditions durinig work time,and offer good protection avoid damage.
5. Generator adopt 24V battery start including no-maintenance start battery.
6. Each generator have been tested two times before delivery.
7. The connection of raditor,generator with under frame, use highly rubber damping block,reduce the vibration during genset moving or running time,make good protect.
8. Raditor, including Double vents, exhaust heat to achieve high efficiency.
9. Experience, all our engineers have years experience in engines and power plant, make it our generators stable and easy operational.
10. Service. Our company do service for the genset during its life time,each two or three monthes will make the contact for user, check the generator conditions, offer support of technology or desgin or other support for your project etc.
11. Spare parts, for complete sets, all spare parts avaible all the time, whatever which time you need them, we can directly send it without delay,and make you can find us all time.
12. Delivery mostly we have more than 100 hundreds sets in stock for sale, make it fast delivery after the payment,no need wait long time.
13. Warranty: All complete generators we offer 2 year warranty, spare parts avaiable at any time.
14. With super tempered base, seamless welding and baking process. Anti-corrosion, anti-weathering, durable.
15. Each set with maintenance book,spare part list and generator operation book etc.

​

​
